LF series impact crusher is a kind of equipment that uses impact energy to crush materials. When unbroken materials enter the crushing chamber, the front and rear impact screens retract and the unbroken materials are discharged from the machine. It is mainly used for medium and fine crushing of medium-hard materials. It is a new type of two-stage medium and fine crushing equipment.
Applicable to nearly 200 kinds of materials including medium hardness, soft materials, limestone, coal gangue, weathered rock, dolomite, magu stone, etc.
It is widely used in many fields, mainly including various ore crushing, metallurgy, roads, energy, cement, chemicals, construction and other industries
|
Model |
Feeding size (mm) |
Maximum material side length (mm) |
Capacity (t/h) |
Installed Power (kw) |
Weight (kg) |
|
LF150 |
820x980 |
500 |
100-200 |
90-200 |
12000 |
|
LF250 |
960x1360 |
500 |
200-400 |
180-250 |
17000 |
|
LF350 |
1050x1700 |
600 |
300-500 |
200-400 |
24000 |
By adjusting the installation position of the impact frame, the coarse crushing and medium and fine crushing can be converted, and one machine can be used for two purposes. The rotor is high in strength and adopts a heavy-duty design.
The feed opening is larger and suitable for crushing large pieces of material. The maximum feed size is 1000mm.
When crushing construction waste, it can effectively prevent steel bar winding.
The plate hammer is made of highly wear-resistant materials with a long service life. It adopts a C-type design to change the striking angle, with high crushing efficiency. The plate hammer is simple and reliable to lock and easy to replace and install.
Key parts are highly interchangeable, effectively extending the service life of consumable parts.
We configured a PE500X750 and PYB900 cone crusher combined mobile station for the customer. The vibrating feeder feeds the granite below 400mm into the PE500x750 jaw crusher for primary crushing, and then it to the PYB900 cone crusher for secondary crushing. The vibrating screen is used to screen out the finished building materials required by the customer.
We configured a PE500X750 and PYB900 cone crusher combined mobile station for the customer. The vibrating feeder feeds the granite below 400mm into the PE500x750 jaw crusher for primary crushing, and then it to the PYB900 cone crusher for secondary crushing. The vibrating screen is used to screen out the finished building materials required by the customer.
We configured a PE500X750 and PYB900 cone crusher combined mobile station for the customer. The vibrating feeder feeds the granite below 400mm into the PE500x750 jaw crusher for primary crushing, and then it to the PYB900 cone crusher for secondary crushing. The vibrating screen is used to screen out the finished building materials required by the customer.
