Shaker Table-Shengbang International Technology (henan) Co., Ltd.

Brief Introduction

Shaker table uses in to classify the granularity 2-0.02 millimeters ore and ore slime the rank tungsten, the tin, the niobium the manganese, the chromium, the titanium, the lead, the zinc, the gold, the iron (red iron, brown iron and so on the metallic minerals.

Application Field

Mining
Metallic minerals
Recycled Aggregates
Architecture

Technical Specification

Name	Coarse sand surface of table	Fine sand surface of table	Ore slime surface of table
Length (mm)	4450	4450	4450
Transmission end width (mm)	1855	1855	1855
Crude ore width (mm)	1546	1546	1546
Max.feeding size (mm)	2	0.5	0.15
Feed amount (tph)	30-60	10-20	15-25
Feed density(%)	25-30	20-25	15-25
Capacity (tph)	0.6-2.5	0.6-2.5	0.6-2.5
Stroke (mm)	16-22	11-16	8-16
Frequency(f)	45-48	48-53	50-57
Water quantity added(tph)	80-150	30-60	10-17
Dressing area(m²)	7.6	7.6	7.6
Cross-section Shape of table surface	Rectangular	Saw tooth	triangle
Motor Power (kw)	1.1	1.1	1.1
Transmission Mechanism		Eccentric linkage

Product Advantages

01
Wide selection granularity.
02
Large processing capacity and low loss.
03
Stable performance and durability.
