What equipment is needed to crush limestone?

Limestone crushing production lines usually include the following main equipment:

1. Feeding equipment: such as vibrating feeder, used to feed large pieces of limestone evenly into the crusher.

2. Primary crushing equipment: Jaw crusher: Because of its large feed port and deep crushing chamber. It is vividly called “tiger mouth”. It has a simple structure, convenient operation, and good environmental performance. It is mainly used for coarse crushing of limestone.

3. Secondary crushing equipment:

Impact crusher: often used in combination with jaw crusher for secondary medium and fine crushing. The rotor runs at high speed. The crushing ratio is large, and the finished particle shape is good and cubic.

Cone crusher: adopts the principle of laminated crushing, with stable crushing effect, suitable for medium and fine crushing operations.

4. Fine crushing equipment (optional):vertical shaft impact crusher (sand making machine): Processes stones with smaller particle size into finer sand and gravel. The output sand and gravel has uniform particle size and reasonable grading.

5. Screening equipment: such as vibrating screen, used to grade the crushed materials to obtain products of different particle sizes.

6. Conveying equipment: such as belt conveyor, used to transport materials from one equipment to another, or from the crushing area to the storage area.

7. Auxiliary equipment: including dust removal equipment, iron remover, etc., used to reduce dust pollution in the production process and remove metal impurities in the material.

Common solution

1. Jaw Crusher + Impact Crusher

 Advantages: The process is mature and reasonable, with high operation rate and moderate equipment investment. The product variety ratio is easy to adjust, the product particle shape is good, and the powder material is less. The process is short, the stone powder content is low, and the finished aggregate particle shape is excellent.

Application: This is a process widely used at home and abroad, especially suitable for the crushing of soft materials such as limestone.

2. Jaw Crusher + Cone Crusher

Advantages: low needle-like content, low proportion of powdery materials in the product, strong wear resistance, and long service life of vulnerable parts (such as the crushing wall and mortar wall of the cone crusher can reach 3~5 years).

Disadvantages: high initial project investment and high maintenance requirements. However, in areas with low requirements for powdery materials, this process has high economic value.

The selection of limestone crushing process and the configuration of crushing equipment is a process that comprehensively considers many factors, including ore particle size, output requirements, finished product particle size requirements, equipment investment, operating costs, and environmental protection requirements.
